2 Inch Electric Hydraulic Hose Crimper 6-51mm with 10 Dies

Brand Name : FY

Model Number : FY-51BY

Certification : CE

Place of Origin : China,Shanghai

MOQ : 1 set

Price : USD$ 1700/1650

Payment Terms : L/C,T/T,D/A,D/P,Western Union,MoneyGram

Supply Ability : 300 sets per month

Delivery Time : 2-7 working days

Packaging Details : wooden box

Voltage : 220V/240V/380V/415V(Optional)

Gross Weight : 326kgs

Net Weight : 310kg

Power(w) : 3KW

Dimension(l*w*h) : 860*640*1300 mm

Package Dimension : 900*685*1410 mm

Warranty : 1 Year

Condition : New

After-sales service provided : Video technical support,Online support

Crimping force : 600Ton

Product name : 2" Electric 6-51mm 1/4 To 2 Inch High Model Basic Model Button System 10 Dies Big Power Portable Hydraulic Hose Crimping Machine/hose Crimper/hose Pressor Excavator Hose Press Tool

Crimping range : 6-51mm

Color : Blue,blue or customize

Application : Crimp Hose

Free dies : 10sets

System pressure : 31.5MPA

Output Volume Of Pump : 2.5L/5L/10L

HIGH LIGHT : Hydraulic Hose Crimping Machine, Flexible Hydraulic Hose Crimping Machine, Flexible Hose Crimping Machine

Contact Now

2" Electric 6-51mm 1/4 To 2 Inch High Model Basic Model Button System 10 Dies Big Power Portable Hydraulic Hose Crimping Machine/hose Crimper/hose Pressor Excavator Hose Press Tool

2 Inch Electric Hydraulic Hose Crimping Machine - High Model

Product Description

Introducing the 2 Inch Electric Hydraulic Hose Crimping Machine, designed for efficient crimping of hoses ranging from 6mm to 51mm (1/4 inch to 2 inches). This powerful and portable crimper features a basic model button system and includes 10 dies for versatile applications, making it an essential tool for excavator and hydraulic hose assembly.

Key Features

Electric Operation: The electric design ensures consistent power and performance, allowing for precise crimping with minimal effort.
Wide Hose Compatibility: Capable of crimping hoses from 6mm to 51mm (1/4 inch to 2 inches), this machine is versatile enough to handle various hydraulic applications.
Basic Model Button System: The intuitive button control system simplifies operation, making it accessible for users of all experience levels.
10 Dies Included: Equipped with 10 different dies, this crimper allows for quick adjustments to accommodate various hose sizes, enhancing efficiency.
Portable Design: Its lightweight and compact design make it easy to transport, ideal for on-site use in excavator and hydraulic applications.

Advantages

Powerful Performance: The electric motor provides robust crimping capabilities, ensuring secure and leak-proof connections for high-pressure hoses.
Versatile Applications: Suitable for a variety of hydraulic hoses, this machine is perfect for automotive, industrial, and excavator tasks.
Ease of Use: The button control system makes operation straightforward, allowing for quick training and efficient use.
Compact and Portable: Designed for mobility, this crimper can easily be moved to different job sites, enhancing convenience.

2 Inch Electric Hydraulic Hose Crimper 6-51mm with 10 Dies

crimping range/skiving range	6-51mm(1/4''-2''inner diameter of hose)
quantity of dies	10 sets
item diesNo. of	length 60mm(15,19,23,26)
	Length 70mm(31,36,41)
	Length 80mm(47,55,60)
accuracy	0.01mm
output volume of pump	2.5L/5L/10L(Optional)
system pressure	26Mpa/31.5Mpa(Optional)
motor power	3kw/4kw 1,2,3 phase (Optional)
voltage	220V/380V/415V(Customizable) 50/60Hz
crimping force	500T
work efficiency	200pcs/h
maximum open diameter	114mm
the max open tolerance	±30mm
package dimension	9006801450mm
machine dimension	8606401300mm
Net weight	310kg
Gross weight	320kg

2 Inch Electric Hydraulic Hose Crimper 6-51mm with 10 Dies

TECHNICAL DATA

Model	FY-51BY Hose Crimping Machine
Crimping Range	6-51(mm)
Crimping Force	600(T)
Hose Size	1/4-2(inch)
Max. Opening	30±mm
Die Sets	10
Maximum Open Diameter	114MM
System Pressure	31.5(Mpa)
Accuracy	0.01(mm)
Work Efficiency	200 pcs/h
Standard Voltage	220v/240v/380v/415v(optional)
Motor Power	3(KW)
Length	860(mm)
Width	640(mm)
Height	1300(mm)
Weight	310(KG)

NOTE

- for non standard die sets;

- Customized die sets are available;

- Special voltage 220V, 240V, 380V,415V are availbale;

OPTIONAL

- Quick Change Tool

- UC control;

2 Inch Electric Hydraulic Hose Crimper 6-51mm with 10 Dies

► TWO MODE EASY ALTERNATED

Automatic or semi-automatic mode can be choosen

2 Inch Electric Hydraulic Hose Crimper 6-51mm with 10 Dies

► FOOT PEDAL SWITCH

Free hands for big hose, more convenient; Double usage, both closing and opening function

2 Inch Electric Hydraulic Hose Crimper 6-51mm with 10 Dies

► PEDAL SWITCH

Foot pedal is standard supplied, the advantage is it can free the hand, so even for big size crimping, crimping will be easy

2 Inch Electric Hydraulic Hose Crimper 6-51mm with 10 Dies

► HIGH QUALITY MOTOR

Copper wire aluminium motor, goof heat releasing

2 Inch Electric Hydraulic Hose Crimper 6-51mm with 10 Dies

► SAFE DIE SET STORAGE

A box inside the machine body for storing the die sets

2 Inch Electric Hydraulic Hose Crimper 6-51mm with 10 Dies

► APPLICATIONS
